| Size | Dia.of chain | TYPE A AM3（ per unit ：mm） | weight KG |
|||||||||||
| L | B | B1 | b | b1 | R | R1 | d3 | d1 | d2 | l1 | l2 | |||
| 24 | 22, 24 | 307 | 138 | 96 | 80 | 34 | 48 | 37.5 | M36 | 60 | 31 | 70 | 61.5 | 17.5 |
| 28 | 26, 28 | 372 | 157 | 116 | 84 | 39 | 58 | 47 | M42 | 68 | 36 | 87 | 73 | 37.6 |
| 32 | 30, 32 | 423 | 180 | 124 | 96 | 45 | 62 | 53 | M52 | 78 | 42 | 101 | 73 | 91.0 |
| 38 | 34, 36, 38 | 482 | 213 | 148 | 104 | 53 | 74 | 58 | M56 | 82 | 49 | 115 | 94 | 107 |
| 42 | 40.42 | 546 | 235 | 164 | 115 | 59 | 82 | 66 | M64 | 90 | 55 | 131 | 106 | 115 |
| 48 | 44, 46, 48 | 615 | 269 | 196 | 125 | 67 | 98 | 75 | M76 | 98 | 62 | 145 | 118 | 139 |
| 52 | 50.52 | 712 | 314 | 218 | 130 | 73 | 109 | 88 | M90 | 107 | 68 | 168 | 135 | 264 |
| 56 | 54, 56 | 712 | 314 | 218 | 138 | 78 | 109 | 88 | M90 | 110 | 73 | 168 | 135 | 270 |
| 62 | 58, 60, 62 | 787 | 348 | 252 | 149 | 88 | 126 | 100 | M100 | 118 | 82 | 185 | 152 | 294 |
| 68 | 64, 66, 68 | 868 | 380 | 265 | 166 | 95 | 136 | 106 | M110 | 128 | 88 | 200 | 150 | 403 |
| 76 | 70. 73. 76 | 965 | 426 | 304 | 168 | 106 | 152 | 120 | M120 | 136 | 100 | 225 | 184 | 464 |
| 81 | 78, 81 | 1,042 | 454 | 328 | 178 | 113 | 164 | 130 | M130 | 145 | 105 | 240 | 183 | 749 |
| 87 | 84.87 | 1,118 | 487 | 352 | 190 | 122 | 176 | 140 | M140 | 152 | 113 | 260 | 214 | 931 |
| 95 | 90, 92, 95 | 1,206 | 532 | 380 | 200 | 133 | 190 | 152 | M150 | 160 | 124 | 280 | 231 | 1191 |
| 102 | 100,102 | 1,308 | 571 | 412 | 220 | 143 | 206 | 164 | M165 | 168 | 133 | 300 | 253 | 1464 |
| 107 | 105.107 | 1,398 | 600 | 420 | 225 | 150 | 210 | 176 | M175 | 178 | 140 | 335 | 269 | 1466 |
| 117 | 111,114,117 | 1,498 | 660 | 460 | 230 | 165 | 230 | 188 | M190 | 184 | 154 | 351 | 315 | 1830 |
